10mm x M5 Plastic Push-In Male Connector

$14.00 $9.00

  • Shipping Icon
    Free
    Shipping
  • Shipping Icon
    Safe
    Payment
  • Shipping Icon
    Best
    Services
SKU:
Categories :
  • Plastic Fittings
  • The 10mm x M5 Plastic Push-In Male Connector is a plastic fitting designed to connect 10mm tubing to a male threaded port. The push-pull mechanism allows for quick and easy installation and removal of the tubing without the need for tools. This type of connector is commonly used in pneumatic systems, fluid transfer systems, and other low-pressure applications where quick disconnects are needed, particularly in medical devices, robotics, or small-scale industrial applications.

    Specification Details
    TYPE M5 Plastic Push-In Male Connector
    DESIGN Push-to-Connect (PTC) Designenables fast, secure, and tool-free tube insertion and removal.
    MATERIAL Composite offers excellent chemical resistance and long-lasting durability in applications exposed to harsh conditions.
    MATERIAL CONSTRUCTION Composite
    WEIGHT (lbs) 0.045
    CONNECTION SIZE 1 10 mm
    CONNECTION SIZE 2 1/8″
    CONNECTION TYPE Push-to-Connect|MBSPT
    CONNECTION TYPE 1 Push-to-Connect
    CONNECTION TYPE 2 Male BSPT
    FINISH Nickel-Plated
    FITTING TYPE Connector
    PRESSURE RATING 150 psi
    TEMPERATURE RATING 32 to 140 deg F
    THREAD SIZE 1/8 – 28
    APPLICATIONS Ideal for Pneumatic Systems,Automotive,HVAC,Industrial Equipment,Water & Beverage Systems
    BRAND Midland Industries
